S420NL Structural Steel Plate, S420NL Steel Plates Manufacturer in Shanghai, EN 10025 S420NL Steel Plate, S420NL Steel Plates Supplier, EN S420NL Low Alloy Structural Steel Plate, S420NL High Strength Structural Steel Plates, EN 10113 S420NL Steel Plates, S420NL Steel Plate Exporter in China, S420NL Steel Plate.

S420NL Structural High Tensile Steel Plates, EN10113-2 S420NL Steel Plate Stockist, S420NL Hot Rolled Structural Steel Plate, EN 1.8912 S420NL Plates, EN 10025-3 S420NL Steel Plate Exporters, S420NL Steel Plate in Shanghai, S420NL Plates Manufacturer in China, S420NL Low Alloy Steel Plates.

S420NL steel plates are a type of steel grade in the EN 10025-3 standard steel. It is containing steel grades like S275N, S460N, S275NL, S420N, S355NL, and A460NL. However, all the grades are supplied in the quality that industry specifies during the time of order and enquiry. CHINA UNITED IRON AND STEEL LIMITED is fully involved in offering the very good quality of steel plates that are produced of using excellent quality of raw substances. With the help of latest technology and modern tools, the production process of steel plates is well improvised. Additionally, the team of professional workers is working harder in order to bring out the best possible quality of the product.

S420NL steel plates are meant for the precision industry, these plates are produced to greater standards. The industry to the buyers is offering the product in various specifications according to the customer’s requirements. The suppliers are too offering customization of plates designed based upon the specifications made by the clients. The industry is providing these plates to the buyers at reasonable rates.

The features which are greatly responsible in increasing the product popularity are many. These are high tensile strength, rugged construction, good dimensional accuracy, durability, flexibility, easy to afford, excellent surface finishes etc. Also, it has various other features to provide withstanding heavy loads, anti-corrosive, general corrosion resistance, longevity etc.

The documentation provided to the industry is raw material test report, material traceability report, guarantee letter, packaging list, commercial invoice, heat treatment chart, quality assurance plan etc.

The mill test certification provided is like third-party test report, lab test report and buyers report etc.

The testing is also considered a major part of the entire production process of S420NL steel plates. These are positive material identification test, hardness test, chemical test, intergranular corrosion test, mechanical test, flattening test, flaring test, macro test, micro test etc.

On regular basis, inspection is welcomed and is done by the expert representative to assure better production of steel plates is done.

When comes to shipping it is packed using standard packaging technique depending upon the nature of the product. This gives safety to the product when shipped.

A buyer can now order it and get heavy discounts.

S420NL Steel Plates Specifications:

Specifications ASTM / ASME
Standard EN 10025-3: 2004 Hot rolled products of structural steels. Technical delivery conditions for normalized/normalized rolled weldable fine grain structural steels
EN 10113-2: 1993 Hot-rolled products in weldable fine grain structural steels. Delivery conditions for normalized/normalized rolled steels
Classification Alloy special structural steel
Thickness 5mm to 150mm
Width 1000mm to 4500mm
Length 3000mm to 18000mm
Dimension range 2-400mm * 1000-3800mm * 3000-18000mm
Supply Condition As Rolled, Vacuum Degassing, Furnace Normalizing, Simulated Post-Weld Heat Treatment or as per customer requirement, Normalized Rolling
Grade Steel S420NL ( 1.8912)
EU
EN
China
GB
Germany
DIN,WNr
USA
France
AFNOR
European old
EN
England
BS
S420NL Q420E TStE420 A572Gr.60
A633E
A633Gr.E
A738Gr.C
E420FP FeE420KTN 50F
C Si Mn Ni P S Cr Mo V N Nb Ti Al Cu CEV
0.2 max 0.6 max 1 – 1.7 0.8 max 0.025 max 0.02 max 0.3 max 0.1 max 0.2 max 0.025 max 0.05 max 0.05 max 0.02 max 0.55 max 0.52 max
Grade Yield Strength
(Min Mpa) Thickness(mm
)
Tensile Strength
(Mpa)
Impacting Test
≤ 16 16-40 40-100 ≥ 100 T<100 T>100 J
S420NL 420 400 390 340 520-680 500-650 -50 27
Application Industry
